Briticom™ Extra Range of wall outlet CAT 6A Screened Module is a cost effective modular and essential quality RJ45 and complies with the EIA TIA Standard for Category 6A. Each shuttered module is supplied with a slide label field and space above. This allows for the use of self adhesive labels or further labelling if required. Termination can be made using Krone tooling. A cable tie base is positioned to the side of the IDC blocks to relieve cable stress. The CAT 6A Screened Module has many applications including LAN Connections, Call Centers and Offices. Made from high quality materials, with labels on each port, it can be used in conjunction with Briticom™ CAT6A Cables and Accessories.
Already bought this product from us? Share your experience on LinkedIn
- Low Profile
- Fits 27mm back box when used with bevelled face-plate
- Built in Slide Label System
- ASDN basic and primary rate Two
- 4.16Mbps Token Ring (IEEE802.5)
- 100 BASE-T4 (Fast Ethernet)
- 10 BASE-T (IEEE802.3)
- 52/155Mbps ATM (ATM Forum)
- 100VG-Any LAN (IEEE802.3)
| Surface Mounted | Yes |
| Flush Mounted Installation | Yes |
| Floor/Sub Floor Mounted | Yes |
| Type of Fastening | Engage (Snap) |
| Type of Connector | RJ45 8(8) |
| Category | 6A |
| Colour | White |
| RAL-Number | 9016 |
| Connection Type | LSA |
| With Label Space | Yes |
| Outlet Direction | Straight |
| Colour Coding | Yes |
| Width of Device | 25mm |
