Briticom® Fibre Optic Connectors are used to mate two fibres to allow a linking between equipment. We offer a full range of fibre connectors in simplex, duplex, with different coloured connectors and boots including 2 and 3mm as well as 900um. With low insertion loss and back reflection capability these connectors are ideal for a variety of telecommunication networks and data centers.
Already bought this product from us? Share your experience on LinkedIn
- Complies with IEC 61754-20 and TIA 604-10-B, FOCIS -10 for inter mate ability
- Low insertion loss and back reflection capability
- Zirconia ceramic ferrule available in several performance grades
- Connector housing and duplex clip available in different colours for easy identification
- RoHS materials
- Telecommunication networks
- LAN, MAN and WAN
- Data centres
- CATV – Cable television
- Fibre-to-the-Home – FTTH
Fibre Optic Connectors
| Standards | Outcome | Conformance | |
| Mating Durability | 500 mating’s | <0.2dB | IEC 61300-2-2 |
| Vibration | 10 – 55Hz, 0.75 amplitude | <0.2dB | IEC 61300-2-1 |
| Drop | Drop height 1m, 5 drops | <0.2dB | IEC 61300-2-12 |
| Cable Retention | Magnitude 70N (LC) & 90 (FC / ST / SC) | <0.2dB | IEC 61300-2-4 |
| Cable Torsion | 1.5 to 2.5kg for 2 to 3mm cable Ø | <0.2dB | IEC 61300-2-5 |
| Operating Temp. | -25 to +70°C – 12 cycles | <0.2dB | IEC61300-2-22 |
| Cold Temp. | -25°C | <0.2dB | IEC 61300-2-17 |
| Dry Heat | +70°C | <0.2dB | IEC 61300-2-18 |
