Briticom® Cat6a SFTP Flat Patch Cord are designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards, including ANSI/TIA-568-C.2:2009 and ANSI/TIA-568.0-D:2017. This delivers Class FA link and channel performance supporting all applications detailed and proposed within the standards. This superior performance cable is ETL component verified.
Already bought this product from us? Share your experience on LinkedIn
- 500 MHz with over 10Gbps
- 25-year warranty
- ANSI/TIA-568-C.2:2009
- ANSI/TIA-568.0-D:2017
- Shielded/Foiled
- LSZH or PVC jacket
- Available in different colours & lengths
- Durable for 750 insertion cycles
- Data centre & Telecommunication networks
- LAN Applications
- CATV – Cable television, CCTV
Cat6a SFTP Flat Patch Cord
| Conductor Type | 32AWG (7/0.08), Stranded Bare Copper |
| Insulation | HDPE |
| Connector Type | Unshielded 8P8C (RJ45) |
| Jacket | PVC/LSZH |
| Minimum Average Thickness | 2.20mm |
| Conductor DC Resistance | 9.38Ω/100m (maximum) |
| Impedance | 100Ω |
| Capacitance | 5600pf/100m |
| Propagation Delay | 545ns/100m (maximum) |
| Delay Skew | 45ns/100m (maximum) |
| Temperature Rating | -20°C to +60°C |
| Typical applications | IEEE 802.3: 10BASE-T; 100BASE-T; 1000BASE-T |
| Norms | ISO/IEC 11801-1; EN-50173; ANSI/TIA-568-C.2:2009, ANSI/TIA-568.0-D:2017; EN 60603-7-5 |
