Briticom® Indoor Fibre Cabinet I5 can be used to house and protect fibre optic cables for pass through, reservation and fibre distribution.
Already bought this product from us? Share your experience on LinkedIn
- Allows quick installation of fibre optic cable
- 4,320 LC ports per cabinet
- Save space through increased port density
- Back-to-back frame configuration
- Modular design
- Front cable access
- Supports standard 1.6 and 2.0 mm patch cords
- RoHS compliant materials
- Glass front door
- Data centres
- Telecommunication networks
- LAN, MAN and WAN applications
- CATV – Cable television
Indoor Fibre Cabinet I5
| Material | Cold-Rolled Steel |
| Dimensions | 2200 × 900 x 300 mm |
| Max Capacity SC | 2880 |
| Max Capacity LC | 4320 |
| Main Frame / Thickness | SPCC, powder coating / 2.0mm |
| Mounting Rail / Thickness | SPCC, powder coating / 2.0mm |
| Doors & Rear Panel | SPCC, powder coating / 1.5mm |
| Front Glass Window | Toughened glass |
| Cable Entrance / Outlet | Top, bottom |
| Operating Temp | ‐10°C to + 60°C |
