Briticom® 32FO Outdoor Splicing Distribution Box are used for the easy-access and distribution of fibre optic connections between networks.
Already bought this product from us? Share your experience on LinkedIn
- 32 LC DX FO
- Wall or pole mount
- 1:8 splitter (2 pcs) or 1:16 PLC splitter (1pc)
- Anti-UV, anti-impact and waterproof
- SC, LC adapters
- IP54 rating
- RoHS materials
- Telecommunication networks
- LAN, MAN and WAN applications
- CATV – Cable television
- Fibre-To-The-Home (FTTH)
32FO Outdoor Splicing Distribution Box
| Material | ABS+PC |
| Dimensions | 231x152x59mm |
| Colour | Grey |
| IP Rated | IP54 |
| Max Splitting | 1:4 (2pcs) / 1:8 (1pc) |
| Weight (kg) | 0.6 |
| Cable Diameter (mm) | ≤ 12mm |
| Inlet/Outlet | 4 in 16 out |
| Fibre Core Capacity | 32 LC DX |
| Optical Fibre Radius of Curvature | ≥40mm |
| Splice Tray Additional Loss | ≤0.01dB |
| Working Temperature | -10℃~+60℃ |
| Side Pressure | ≥2000N/10cm |
| Impact Resistance | ≥20N.m |
