Briticom® Outdoor Splicing Distribution 08 FO fibre optic distribution and termination boxes are used for the easy-access and distribution of fibre optic connections between networks. With Anti UV, Anti Impact and Waterproof features its an ideal distribution box for outdoor applications such as fibre to the home (FTTH) and telecommunication networks. It is able to be wall or pole mounted with an IP54 Rating.
Already bought this product from us? Share your experience on LinkedIn
- 08 FO
- Wall or pole mount
- 1:4 splitter (2 pcs) / 1:8 splitter (1 pc)
- Anti-UV, anti-impact and waterproof
- SC adapters
- IP54 rating
- RoHS materials
- Telecommunication networks
- LAN, MAN and WAN applications
- CATV – Cable television
- Fibre To The Home (FTTH)
| Material | ABS + PC |
| Dimensions | 192 x 132 x 52 mm |
| Colour | White |
| IP Rated | IP54 |
| Max Splitting / Fibre Core Capacity | 1:4 (2 pcs) / 1:8 (1 pc) / 8 (single fibre) |
| Weight (kg) | 0.5 |
| Optical Fibre Radius of Curvature | ≥ 30mm |
| Splice Tray Additional Loss | ≤ 0.01dB |
| Working Temperature | – 10℃ ~ +60℃ |
| Side Pressure | ≥ 2000N / 10 cm |
| Impact Resistance | ≥ 20N.m |
| Cable Diameter (mm) | ≤ 12mm |
| Inlet/Outlet | 2 in 8 out |
| Mounting | Wall or Pole |
Outdoor Splicing Distribution 08 FO
DOWNLOAD DATASHEET
