Briticom® offers ADSS Multi Tube Aerial Cable as well as a wide range of indoor and outdoor fibre optic distribution, patching and consumer cables including Plenum, Riser and LSZH in all diameters. These are used to provide links to protocols such as FTTH, FDDI, 10 Gigabit Ethernet, ATM.
Already bought this product from us? Share your experience on LinkedIn
- IEC Standard 60529
- High tensile strength
- For outdoor aerial use
- Water, flame and rodent resistant
- Available in many colours
- Telecommunication networks
- CATV – Cable television
ADSS Multi Tube Aerial Cable
| Fibre Count | 24 FO | 48 FO |
| Outer Diameter (mm) | 8.20 | 9.70 |
| Weight per Km | 53 | 72 |
| Max loading operating tension (N) | 1670 | 1800 |
| Mini Bend Radius dynamic (mm) | 17 | 20 |
| Span | 53 m | 55 m |
| Crush | 300/1000 N | 300/1000 N |
| Operating Temp. (⁰C) | -40 ~ 70 | |
