Briticom® Cat6 U/UTP Lockable Patch Cord are designed and manufactured to meet and exceed the ISO, CENELEC and TIA standards. This delivers Class FA link and channel performance supporting all applications detailed and proposed within the standards. This superior performance cable is ETL component verified
Already bought this product from us? Share your experience on LinkedIn
- 250 MHz with over 2.5Gbps
- ANSI/TIA-568-C.2 Standard of 2009
- ANSI/TIA-568.0-D Standard of 2017
- ANSI/TIA/EIA-568-B.2.10
- 25-year warranty
- Unshielded
- LSZH, PVC or PE jacket
- Available in different colours
- Available in different lengths
- Durable for 750 insertion cycles
- Data centres
- Telecommunication networks
- LAN applications
- CATV – Cable television
- CCTV
Cat6 U/UTP Lockable Patch Cord
| Conductor | Stranded AWG 26 |
| Insulations | FO-PE (Foamed Polyethylene) |
| Overall diameter | 5.8 mm ± 0.30 mm |
| Bending radius | 15 x OD |
| RJ45 connector | 3 μ nominal gold flash over 60 μ nickel undercoat contact pins |
| Contact resistance | 20 mΩ |
| Dielectric strength | 2500 VDC for 3 seconds |
| Insulation resistance | 500 mΩ |
| Voltage | 150v |
| Flame retardance, Smoke emission | IEC 60332-1, IEC 61034 |
| Typical applications | IEEE 802.3: 10BASE-T; 100BASE-T; 1000BASE-T |
| Norms | ISO/IEC 11801-1; EN-50173; ANSI/TIA-568-C.2; NSI/TIA-568.0-D; EN 60603-7-5, ANSI/TIA/EIA-568-B.2.10 |
