Briticom® FTTH Round Drop Cable is a tight buffered fibre available in many colours. We offer a wide range of indoor and outdoor fibre optic distribution, patching and consumer cables including Plenum, Riser and LSZH in all diameters. These are used to provide links to protocols such as FTTH, FDDI, 10 Gigabit Ethernet, ATM.
Already bought this product from us? Share your experience on LinkedIn
- Available in many colours
- Strength Member
- Tight-buffered Fibre
- Outer Jacket
- Telecommunication networks
- CATV – Cable television
- Fibre-To-The-Home (FTTH)
- Wall outlets to Desk
Cable Parameters
| Fibre Count | 2 |
| Color coding Fiber | |
| Dimension Color |
250mm±15μm Blue Orange |
| Loose Buffer | |
| Dimension Material Color |
850±50μm LSZH white |
| Strength Member | Aramid yarns |
| Outer Jacket | |
| Dimension Material Color |
3.0mm±0.2mm (thickness is about 0.7mm) LSZH Black |
Mechanical & Environmental Characteristics
| Tension (Long Term) | 225N |
| Tension (Short Term) | 450N |
| Crush (Long Term) | 100 N/10cm |
| Crush (Short Term) | 500 N/10cm |
| Min. Bend Radius (Dynamic) | 20D mm |
| Min. Bend Radius (Static) | 10D mm |
| Installation Temperature | -20 ~ 60 ⁰C |
| Operating Temperature | -30 ~ 60 ⁰C |
| Storage Temperature | -30 ~ 60 ⁰C |
