Briticom® offers 2-FRP Horizontal Flat Cable as well as a wide range of indoor and outdoor fibre optic distribution, patching and consumer cords including Plenum, Riser and LSZH in all diameters. These are used to provide links to protocols such as FTTH, FDDI, 10 Gigabit Ethernet, ATM. This product has for outdoor use and is water, flame and rodent resistant. It is available in a wide range of colours and is suitable for many different applications including data centres and telecommunications networks, CATV Cable Television and Fibre to the Home (FTTH). It can also be used in Outdoor Datacomms.
Already bought this product from us? Share your experience on LinkedIn.
- Flat Loose Tube
- For outdoor use
- Water, flame and rodent resistant
- Available in many colours
- Data centre & Telecommunication networks
- CATV – Cable television
- Fibre to the Home (FTTH) & Telecom
- Indoor/Outdoor Datacomms
2-FRP Horizontal Flat Cable
| Outer Sheath | PE |
| Fibre Count | 1 – 12 |
| Outer Diameter (mm) | (7.5 ± 0.3) x (4.2 ± 0.2) |
| Max Tensile Strength (N) | 1500 |
| Min. Bend Radius (mm)
Dynamic Static |
20D 10D |
| Max Crush Resistance (N/10cm) | 2000 (long term 1000 N) |
| Operating Temp. (⁰C) | -40 to 70 |
| Attenuation (max. dB/km)
1310nm 1550nm |
≤0.36 ≤0.22 |
| Strength members | 2mm x 2 FRP |
