Briticom® professional V-shaped 24-port STP patch panel offers a perfect solution for high density applications. As the panel is angled you can manage 12 patch cords easy from both sides, so there is a better cable management inside of the rack.
Already bought this product from us? Share your experience on LinkedIn
- V-Design for better patch cord management
- A rear bar for tidier cable management at the back
- 24 modular ports
- 24 number & 24 labels
- Earthing/grounding
- Available in 1U, 0.5U, and with Shutters
- ANSI/TIA-568-C.2 Standard of 2009
- ANSI/TIA-568.0-D Standard of 2017
- Data & Server Racking
- Cat 5e, Cat 6 & Cat 6a RJ45 Modular Jacks
- Data Centres & LAN installations
V-shaped 24-port STP patch panel
| Norms | ISO/IEC 11801 3rd Ed., EN 50173-1, ANSI/TIA-568-C.2, ANSI/TIA-568.0-D |
| Housing material | 1.5 mm SPCC cold rolled steel sheet, powder-coated |
| Material standard | EN 10 130(1991), BS 1449, NFA 36/401, DIN 1623, UNI 5866, ASTM, SAE, NFA 36/401 |
| Grounding | Central ground connection |
| Operation Temperature | -20° C to +70 °C (ISO/IEC 11801, EN 50173-1, ANSI/TIA-568-C.2) |
