Briticom® offers Horizontal Laminated Aluminium Cable as well as a wide range of indoor and outdoor fibre optic distribution, patching and consumer cord including Plenum, Riser and LSZH in all diameters. These are used to provide links to protocols such as FTTH, FDDI, 10 Gigabit Ethernet, ATM. This product is water, flame and rodent resistant as well as being available in a wide variety of colours. This item is suitable for a wide range of applications such as CATV Cable Television and Fibre to the Home (FTTH).
Already bought this product from us? Share your experience on LinkedIn
- Multi Tube – Aluminium Tape Armoured
- For outdoor use
- Water, flame and rodent resistant
- Available in many colours
- CATV – Cable television
- Fibre To The Home (FTTH)
- ODFs to Wall outlets, Wall outlets to Desk
Horizontal Laminated Aluminium Cable
| Outer Sheath | HDPE |
| Fibre Count | 72 |
| Outer Diameter (mm) | 12.5±0.5 |
| Max Tensile Strength (N) | 2700 |
| Min. Bend Radius (mm)
Dynamic Static |
20D 10D |
| Max Crush Resistance (N/100mm2) | 2800 |
| Operating Temp. (⁰C) | -40 to 70 |
Horizontal Laminated Aluminium Tape Cable
