Briticom® Duplex Patch Cable offers a wide range of indoor and outdoor fibre optic distribution, patching and consumer cables including Plenum, Riser and LSZH in all diameters. These are used to provide links to protocols such as FTTH, FDDI, 10 Gigabit Ethernet, ATM. Available with a double jacket and in many different colours its suitable for many applications including data centres, telecommunications networks, fibre to the home (FTTH) and Connections between patch panels and boxes. As well as these cables, Briticom® offers a wide range of Indoor Cables and other Fibre Optic products.
Already bought this product from us? Share your experience on LinkedIn
- Duplex – 2 Cores
- Double jacket available
- Available in many colours
- Data centre & Telecommunication networks
- CATV – Cable television
- Fibre To The Home (FTTH)
- ODFs to Wall outlets, Wall outlets to Desk
- Connections between patch panels & boxes
Duplex Patch Cable
| Buffer Material | PVC, PE or LSZH | |||
| Outer Diameter (mm) | 1.6 | 1.8 | 2.0 | 2.8 |
| Weight per Km | 5.7 kg | 6.7 kg | 8.2 kg | 13.2 kg |
| Max. Tensile Strength (N)
Short Term Long Term |
160 80 |
160 80 |
200 100 |
300 160 |
| Min. Bend Radius (mm)
Dynamic Static |
20D 10D |
|||
| Max. Crush Resistance (N/100mm2) | 1000 | |||
| Operating Temp. (⁰C) | -20 to 70 | |||
